Description
The Genesis ESS225 Outdoor Stainless Steel Straight Edge Tile Trim is a 22.5mm Grade 304 stainless steel profile designed for external use with 2cm tiles. It gives lasting edge protection on balconies, terraces, patios and landscaping, with weatherproofed, corrosion-resistant durability in a brushed or polished finish.
Key benefits
- 22.5mm height suits 2cm outdoor porcelain tiles
- Grade 304 stainless steel for corrosion resistance and lasting durability
- Weatherproofed profile designed for external use
- Choice of Brushed or Polished finish
- Polished finish supplied with a removable protective film
- Perforated 35mm anchoring leg keys securely into tile adhesive
Applications
Used by professional tilers, landscapers, builders and DIY users to finish exposed tile edges on balconies, terraces, patios, steps and other external areas. Suitable for porcelain, ceramic and natural stone tiles and slabs.
Performance and features
- Profile: L-shaped straight edge (ESS225)
- Height: 22.5mm
- Flange: 35mm wide, 0.8mm thick, perforated
- Length: 2.5m
- Material: Grade 304 stainless steel
Compatibility
Choose Brushed or Polished from the Finish option and select the profile to suit your tile thickness. It is bedded into tile adhesive and works with ceramic, porcelain and natural stone tiles. Stainless steel is not rustproof in harsh environments such as swimming pools, where chlorine and bromine are highly corrosive, so regular cleaning is advised. Pair with Millcot flexible tile adhesives, grouts and tanking systems for a complete outdoor installation.
Supplied by Millcot, your trusted UK trade supplier of tiling, wetroom and building products.
Technical specifications
- Brand: Genesis
- Range: ESS225 Balcony & Landscaping Stainless Steel Straight Edge
- Profile: L-shaped straight edge
- Height: 22.5mm
- Flange width: 35mm
- Flange thickness: 0.8mm
- Length: 2.5m
- Material: AISI 304 / DIN 1.4301 stainless steel
- Finish: Brushed (102) or Polished (84)
- Fitting type: Bedded in tile adhesive, mechanical fix if required
- Use: External
- Pack quantity: 1 x 2.5m length
What's included
- 1 x 2.5m Genesis ESS225 Outdoor Stainless Steel Straight Edge Tile Trim in your chosen finish
Frequently asked questions
What tile thickness is the ESS225 for?
It has a 22.5mm height and is designed for use with 2cm tiles.
What grade of stainless steel is it?
All Genesis stainless steel profiles are manufactured from Grade 304 stainless steel.
What is the difference between Brushed and Polished?
Brushed has a satin, directional finish that hides marks well. Polished is bright and reflective and is supplied with a removable protective film, which can stay on before, during and after installation.
How do I fix it?
Trowel tile adhesive around the tiled perimeter, press the perforated anchoring leg into the adhesive and align it, then trowel more adhesive over the leg. Embed the tiles so the tiled surface is flush with the top of the profile, with the profile never higher than the tiles and up to about 1mm lower. Then fill the joint completely with grout. Mechanical fixing is possible if required.
Can it be used around swimming pools?
Genesis advise that stainless steel is not rustproof in the harsh chlorine and bromine environment of a swimming pool, so it needs regular cleaning. Check suitability for your application.
How do I clean it?
Clean regularly with a non-abrasive cleaner and water, remove rust spots promptly, and never use steel wool, sandpaper or bleach. Exposed edges can be sharp, so wear protective gloves when handling.
Download the Genesis ESS225 Outdoor Stainless Steel Straight Edge Technical Datasheet (PDF)
